ABB Flame Detection Fiber Optic Cable SF810-F0-G-2400: Technical Specifications & Product Overview
In the critical realm of industrial combustion and flame safety, reliable signal transmission from the combustion chamber to the flame scanner is paramount. The ABB SF810-F0-G-2400 is a specialized flame detection fiber optic cable engineered precisely for this demanding task. This product introduction provides a detailed overview of its technical parameters, construction, and key features, establishing it as a vital component for robust flame safety systems.
Product Overview
The ABB SF810-F0-G-2400 is a high-temperature, flexible fiber optic conduit designed to transmit ultraviolet (UV) and/or infrared (IR) radiation from the burner front to a remotely mounted flame scanner, such as the ABB UVISOR® FFlame series. By relocating the sensitive electronics away from extreme heat and vibration, this fiber optic cable significantly enhances scanner longevity and system reliability. It is the essential link for accurate flame monitoring in applications like gas, oil, and dual-fuel burners.
Key Features & Benefits
-
High-Temperature Resistance: The core feature is its ability to withstand the intense heat of the boiler or furnace environment, protecting the scanner.
-
Robust Mechanical Construction: Designed with flexibility and durability to handle industrial vibration and minor mechanical stress during installation and operation.
-
Precision Optical Transmission: Optimized to efficiently transmit the specific UV and/or IR wavelengths critical for flame discrimination with minimal signal loss.
-
Proven Compatibility: Designed for seamless integration with a wide range of ABB's industry-leading flame scanners.
Detailed Technical Parameters & Specifications
The following table outlines the core technical specifications for the ABB SF810-F0-G-2400 fiber optic cable.
Applications
The SF810-F0-G-2400 is indispensable in any industry requiring reliable flame supervision, including:
-
Power Generation: Utility and industrial boilers.
-
Oil & Gas: Process heaters and fired reactors.
-
Pulp & Paper: Recovery boilers and lime kilns.
-
Any application utilizing ABB flame scanners that require remote mounting via a fiber optic light guide.
Conclusion
The ABB SF810-F0-G-2400 flame detection fiber optic cable is a critical, high-performance component designed for mission-critical flame safety systems. Its robust construction, high-temperature resilience, and precise optical characteristics ensure the reliable transmission of flame signals, enabling the flame scanner to make accurate and safe burner management decisions. By specifying this cable, engineers ensure the integrity and longevity of their combustion control and safety infrastructure.
